KOSO Digital Multifunction Cockpit, DB-02, battery version

Upgrade Your Ride with the KOSO Digital Multifunction Cockpit, DB-02, Battery Version

Experience clear, real-time data that keeps you in control and focused on the road. The KOSO Digital Multifunction Cockpit, DB-02, battery version offers unbeatable value by combining multiple essential readouts into one compact, easy-to-read display—perfect for riders who want precision without breaking the bank.

Features & Benefits of the KOSO Digital Multifunction Cockpit, DB-02, Battery Version

• Multi-Function Display: Speedometer, odometer, trip meter, clock, and fuel gauge all in one unit for quick, at-a-glance info.
• Battery-Powered Convenience: No wiring hassle—easy installation with long-lasting battery operation.
• Compact & Lightweight: Sleek design fits most motorcycles without adding bulk or weight.
• Clear LCD Screen: High-contrast display ensures visibility in all lighting conditions, day or night.
• Durable Build: Weather-resistant casing stands up to rain, dust, and vibration on every ride.

With the KOSO Digital Multifunction Cockpit, DB-02, battery version, you get precise, reliable data that helps you monitor your bike’s performance and ride smarter. Whether you’re cruising city streets or hitting the open highway, this cockpit keeps you informed without distraction.

Limited stock available! This popular gadget is flying off shelves fast—don’t miss your chance to upgrade your bike’s dashboard with KOSO’s trusted technology.

Ready to ride smarter? Add the KOSO Digital Multifunction Cockpit, DB-02, battery version to your cart now and enjoy a clearer, safer, and more connected ride today!

Not for use in road traffic! Only for show and racing purposes!

KOSO digital multifunction cockpit, DB-02 (battery version) without ABE
The new DB02 works with an internal battery and was developed primarily for OFF-ROAD ATVs and motorcycles, which are usually not equipped with their own battery. The new dynamic design of the DB-02 connects very well with most motorcycles and ATV's. The bar tachometer is RPM adjustable so it can be adapted to different engine types. The new three-stage shift light allows you to visually signal the perfect shift time. In addition to the bar speed display, we have also integrated a switchable digital rev counter in the DB02, which can be switched on instead of the speed display.

Speed Display: Range: 0 - 360 km/h (0 - 225 MPH)
Display reaction: < 0.5 sec
Total Odometer: Range: 0 - 99999 km (miles)
automatic reset after 99999 km (miles)
Unit: 1 km (miles)
Tripmeter A/B: Range: 0-999.9 km (miles)
automatic reset
after 999.9 km (miles)
Unit: 0.1km(miles)
Speed Limit Warning Light: Range: 30 - 360km/h
(19 - 225 MPH)
Setting unit: 1 km/h (MPH)
top speed
Recording: 0-360 km/h (MPH)
Wheel circumference: adjustment range: 300 - 2500 mm
Adjustment unit: 1mm
Sensor points 6
Digital tachometer: Range: 20,000 rpm
Unit: 10 rpm
60 segment
Bar Tachometer: Range:
10,000 rpm / 166 rpm per segment
15 000 rpm / 250 rpm per segment
20,000 rpm / 333 rpm per segment
Main shift light: Range: 5000 - 20 000 rpm Setting unit: 100 rpm
Front light A / B: Range 500 - 5000 rpm
in front of the main shift light
Setting unit: 100 rpm
Maximum speed absorption: range: 0 - 20 000 rpm
RPM input pulse: 0.5, 1, 1.5, 2, 2.5 3, 4, 5, 6
Running time meter: range 0 - 999.9 hours
Thermometer: °C / °F
Thermometer A/B:: Range: 0 - 250°C
(32 - 482°F)
Unit: 0.1°C (°F)
Temperature alarm A/B:B: Range: 60°C - 250°C
(140°F - 482°F)
Unit: 1°C (°F)
:Maximum Temperature Recording: Range 0 - 250°C (32°F - 482°F)
:Voltmeter: Range: DC 0 - 18.0V
Unit: DC 0.1V
Backlight: DC 12V
Battery type: CR2032
Battery life cycle: approx. 220 hours
Operating temperature: -10°C - +60°C
Device standard: JIS D 0203 S2
Size: 100*60*20mm
Weight: about 200g
Lights: Speed limit: red
Temperature alarm: red
Front light A: yellow
Front light B: orange
Main shift light: red

Scope of delivery: 1 piece
